23 & 40 WATT SELF BALLASTED SCREW IN INDUCTION LAMP/BULB
Induction lamps are ideal replacement lamps for outlawed mercury lamps in outdoor fixtures. Because they are self-ballasted, installation is simple and easy: Just screw them into existing sockets. They also offer bright white, glare-free light with a CRI above 80 for greater visibility and safety. The lamp’s ballast is made of long life components that offer instant, flicker-free cold start and hot restart.
40 WATT MUSHROOM INDUCTION LAMP/BULB
Induction lamps are ideal replacement lamps for outlawed mercury lamps in outdoor fixtures. Because they are self-ballasted, installation is simple and easy: Just screw them into existing sockets. They also offer bright white, glare-free light with a CRI above 80 for greater visibility and safety. The lamp’s ballast is made of long life components that offer instant, flicker-free cold start and hot restart.
HIGH BAY ROUND TYPE LAMP FIXTURE
1. Vaccum coated inner surface aluminum hood and high luminousness PC cover maximize lumen output
2. Wave -shaped reflector optimize light distribution
3. Special thermal design for longer lifespan
4. IP Class: IP53
LAMP AND BALLAST
1. Impact’s 100-300W round type induction lamp with high lumen efficiency, high lumen maintenance , long lifespan and excellent CRI
2. Impact’s 100-300W electronic ballast with die cast aluminum case features high power factor(>0.96), low energy loss and long lifespan
APPLICATION
Industrial factory, warehouse, stadium, airport, railway station, gas station, supermarket and other indoor locations
HIGH BAY HOOD SHAPE LAMP FIXTURE
1. Vaccum coated inner surface aluminum hood and high luminousness PC cove maximize lumen output
2. Powder coated hood for better appearance
3. Special designed hood shape for high luminaire efficiency
4. Special thermal design for longer lifespan
5. IP Class: IP53
LAMP AND BALLAST
1. Impact’s 100-300W round type induction lamp with high lumen efficiency, high lumen maintenance, long lifespan and excellent CRI
2. Impact’s 100-300W electronic ballast with die cast aluminum case features high power factor(>0.96), low energy loss and long lifespan
APPLICATION
Industrial factory, warehouse, stadium, airport, railway station, gas station, supermarket and other indoor locations
HIGH BAY PROFILED ALUMINUM LAMP FIXTURE
1. Vaccum coated inner surface aluminum hood and clear glass cover maximize lumen output
2. Tempered glass cover held by profiled aluminum ring for better appearance and durable use
3. Special thermal design for longer lifespan
4. IP Class: IP65 (If use 3/4’’hanging pole with ribbons), IP53(If use hook)
LAMP AND BALLAST
1. Impact’s 80-250W round type induction lamp with high lumen efficiency, high lumen maintenance, long lifespan and excellent CRI
2. Impact’s 80-250W electronic ballast with die cast aluminum case features high power factor(>0.96), low energy loss and long lifespan
APPLICATION
Industrial factory, warehouse, stadium, airport, railway station, gas station, supermarket and other indoor locations locations
HIGH BAY DIAMOND SHAPE LAMP FIXTURE
1. Vaccum coated inner surface aluminum hood and clear glass cover maximize lumen output
2. Tempered glass cover held by profiled aluminum ring for better appearance and durable use
3. Diamond-shaped reflector optimize light uniformity
4. Special thermal design for longer lifespan
5. IP Class: IP65 (If use 3/4’’hanging pole with ribbons), IP53(If use hook)
LAMP AND BALLAST
1. Impact’s 100-250W round type induction lamp with high lumen efficiency, high lumen maintenance , long lifespan and excellent CRI
2. Impact’s 100-250W electronic ballast with die cast aluminum case features high power factor(>0.96), low energy loss and long lifespan
APPLICATION
Industrial factory, warehouse, stadium, airport, railway station, gas station, supermarket and other indoor locations
HIGH BAY PROFILED ALUMINUM II LAMP FIXTURE
1. Vaccum coated inner surface aluminum hood and clear glass cover maximize lumen output
2. Tempered glass cover held by profiled aluminum ring for better appearance and durable use
3.Special thermal design for longer lifespan
4. IP Class: IP65 (If use 3/4’’hanging pole with ribbons), IP53(If use hook)
LAMP AND BALLAST
1. Impact’s 150-400W round type induction lamp with high lumen efficiency, high lumen maintenance, long lifespan and excellent CRI
2. Impact’s 150-400W electronic ballast with die cast aluminum case features high power factor(>0.96), low energy loss and long lifespan
APPLICATION
Industrial factory, warehouse, stadium, airport, railway station, gas station, supermarket and other indoor locations locations
HIGH BAY THERMAL DESIGN LAMP FIXTURE
1. Heat resistant and high luminousness hood for high luminaire efficiency and uniform lumen output
2. Special thermal design for longer lifespan
3. IP Class: Ip53
LAMP AND BALLAST
1. Impact’s 80-400W round type induction lamp with high lumen efficiency, high lumen maintenance, long lifespan and excellent CRI
2. Impact’s 80-400W electronic ballast with aluminum case features high power factor (>0.96), low energy loss and long lifespan
APPLICATION
Industrial factory, warehouse, stadium, airport, railway station, gas station, supermarket and other indoor locations
HIGH BAY STEEL HOUSING FIXTURE
1. Welded steel housing with high luminousness PC cover
2. Powder coated housing for corrosion resistance
3. High reflection efficiency reflector imported from Germany Alanod aluminum company
4. IP Class: Ip20
LAMP AND BALLAST
1. Impact’s 100-300W round type induction lamp with high lumen efficiency, high lumen maintenance, long lifespan and excellent CRI
2. Impact’s 100-300W electronic ballast with aluminum case features high power factor (>0.96), low energy loss and long lifespan
APPLICATION
Industrial factory, warehouse, stadium, airport, railway station, gas station, supermarket and other indoor locations locations
HIGH BAY THERMAL DESIGN LAMP FIXTURE
1. Profiled aluminum main housing and die cast aluminum side covers with heat resistance and gas tight rubber seal for high IP rating
2. High reflection efficiency reflector imported from Alanod aluminum company
3. Tempered glass cover for shock resistance and durable use
4. Front opening structure for easy installation and maintenance
5. Separated lamp housing and gear box for longer lifespan
6. IP Class: IP65
LAMP AND BALLAST
1. Impact’s 150-400W rectangle type induction lamp with high lumen efficiency, high lumen maintenance, long lifespan and excellent CRI
2. Impact’s 150-400W electronic ballast with dia cast aluminum case features high power factor(>0.96), low energy loss and long lifespan
APPLICATION
Industrial factory, warehouse, stadium, airport, railway station, gas station, supermarket and other indoor locations
